Service Items & Reliability Test

Various Electronics SMT Products, Insertions, Assembly, Testing, Repairing, Burn in

  • SMT: Double Sides and Lead free process.
  • PTH: Dual Wave Soldering and Multi Point Soldering.
  • F/G: Assembly, Packing, and Test

Reliability Laboratory

  • Programmable Temperature & Humidity Chamber
    (Model:MHU-800-LB)

    Testing Purpose:

    1. Temperature Range:-40℃~+150℃
    2. Temperature Control:±0.2℃
    3. Range:±1.0℃(80℃~100℃:±1.5℃)
      (101℃~150℃:±2℃)
    4. Min. Temperature :-40℃
    5. Warm Up time:From -40℃ to 100℃ required 45 mins
    6. Cooling time:From +20℃ to -40℃ required 80 mins
    7. Humidity Range :10%~98%R.H.
    8. Humidity control stability :±2.5%R.H.
    9. Distribution of all degrees : ±5%
  • Burn In Chamber and Aging Oven

    Testing Purpose:

    • Temperature Rang: 25~80℃
    • Use a heating environment to speed up the aging effect on material.
    • Product is before being to use and work for some time to stabilize product performance. Completion of electronic products, deliberately placed in a high temperature before shipment, placed for some time ( seven days), and continue to carry out simulation work to test changes in circumstances in which they are an accelerated aging test , also known as test for life .
  • Low-temperature Refrigerator Precision Hot-Air Oven

    Testing Purpose:

    • Used to test the material structure or composite material, in an instant by the extremely high temperatures and extremely low temperature environment can tolerate continuous, whereby the shortest chemical changes due to thermal expansion and contraction in the room to test its physical injury arising out of or harm which is applicable objects including metal, plastic, rubber, electronics, …etc . Material can be used as a basis for improvement of their products or reference.
  • Vibration Tester (Model:VS-5060L)

    Testing Purpose:

    • Detection products in the shipping process operating environment and endurance can withstand vibrations to improve product reliability.



  • Drop Test System (Model:(KD-128A)

    Testing Purpose:

    • For packaging the finished product, its packaging materials test the extent of shock impact resistance, coating capability and products to verify the adequacy of body. In order to determine the relevant packaging design improvement points, free drop test is used to assess the characteristics of the product due to improper use of action arising fall. And strength and toughness required for product evaluation under safe conditions. Repeatability of free fall (repeated free fall) test is based on regular objects fall to the surface of a hard situation.
  • Hipot Tester (Model: Chroma 19032)

    Testing Purpose:

    • The tester is automatic for pressure、 insulation and ground Tester. And electrical and electronic equipment are for doing automated voltage、 insulation resistance、ground resistance、short and open circuit detection equipment designed.
  • Hazardous Substances testing machine
    (Model: XRF-SEA1000A)

    Testing Purpose:

    • Detection of plastic and electronic components harmful heavy metal substances (RoHS)
